EPOMAKER MAGFORCE 68

EPOMAKER Magforce 68 – Technical Specifications

Layout & Design

• Model: Magforce 68

• Brand: EPOMAKER

• Layout: 65% ANSI (US) with 68 keys

• Case Material: Anodized Aluminum

• Mounting Style: Top-mount (No flex-cut)

• Typing Angle: 7°

• Dimensions: 314.5 × 113.9 × 38.6mm

• Weight: 1.5kg (approx. 2kg with packaging)

Connectivity & Compatibility

• Connection: USB Type-C (wired)

• Compatibility: Windows

Build & Sound Dampening

• Plate Material: FR4

• PCB Thickness: 1.6mm

• Stabilizers: Plate-mount

• Dampening: Poron sandwich foam, bottom foam, bottom EVA

Keycaps & Lighting

• Profile: Cherry

• Material: PBT (Double-shot)

• RGB: South-facing, per-key RGB

Performance

• Polling Rate: 8000Hz

• Scan Rate: 32kHz per key

• Latency: 0.125ms (USB)

• Anti-Ghosting: N-Key Rollover

Switches – Gateron Magnetic Jade Switch Pro

• Type: Magnetic

• Pre-Lubed: Yes

• Initial Force: 36±5gf

• Bottom-out Force: 50±10gf

• Total Travel: 3.5±0.1mm

• Magnetic Flux: 120±8Gs (initial), 700±30Gs (bottom-out, on 1.2mm PCB)

• Lifespan: 100 million keystrokes
